Schneider Electric Universal Power Supply, Phaseo, 1 or 2 Phase, 100 to 500 V, 24 V, 5 Amp
Product details
| Management number | 212286280 | Release Date | 2026/04/06 | List Price | $36.00 | Model Number | 212286280 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
This ABL8 regulated switch mode power supply (SMPS) supplies direct current voltage. It has a rated input of 100V to 500V AC, a rated output current of 5A at 24V DC and a rated power output of 120W. Most of these power supplies have auto protection reset. A few have auto / manual protection reset. Some of these power supplies can be mounted directly to a panel. It is also equipped with a PFC (Power Factor Correction) filter. It has LED diagnostics indicator available in the front for troubleshooting instantly. Automatic reset allows short-term faults to be cleared and systems to restart without the need to disturb on-duty maintenance engineers. It installs on DIN rail and is 56mm-wide. It weighs 0,700kg. It is a power supply for industrial use, rail mounting. It conforms to UL 508, CSA C22.2 No 60950-1 standards. The GB2CD07, GB2CD08, GV2RT06 and GV2ME06 thermal magnetic circuit breakers are recommended for its protection. It has LED diagnostics indicator available in the front for troubleshooting instantly. It installs on DIN rail. It brings energy to your automated systems. Designed for simple machines and applications, modular power supplies are primarily appreciated for their extreme compactness.
- Power your automation equipment with the ABL8 regulated switch mode power supply (SMPS), providing direct current voltage with a rated input of 100V to 500V AC, a rated output current of 5A at 24V DC and a rated power output of 120W
- Equipped with a PFC (Power Factor Correction) filter, this SMPS is ideal for industrial use, with rail mounting and conforming to UL 508, CSA C22.2 No 60950-1 standards; it weighs only 0.700kg and 56mm-wide
- Automatic reset allows short-term faults to be cleared and systems to restart without the need to disturb on-duty maintenance engineers; it has an LED diagnostics indicator available in the front for troubleshooting instantly
- Install on DIN rail or directly to a panel for easy integration into your power supply setup; recommended thermal magnetic circuit breakers for protection are GB2CD08, GV2RT06 and GV2ME06
- From simple machines to automated systems, this module brings energy to your applications, providing reliable power supply without compromising on compactness
| Brand | Schneider Electric |
|---|---|
| Wattage | 120 watts |
| Unit Count | 1.0 Count |
| Form Factor | Rack-mountable |
| Item Weight | 0.7 Kilograms |
| Manufacturer | Schneider Electric |
| Model Number | ABL8RPS24050 |
| Cooling Method | Air |
| Current Rating | 5 Amps |
| Output Wattage | 120 Watts |
| Item Dimensions | 6.5 x 5.71 x 3.07 inches |
| Mfr Part Number | ABL8RPS24050 |
| Compatible Devices | Personal Computer |
| Maximum Input Voltage | 500 Volts (AC) |
| Minimum Input Voltage | 100 Volts |
| System Bus Connector Type | 20+4 Pin |
| Global Trade Identification Number | 03389119405614 |
